FYTB 30 TF/VA228 - SKF FYTB 30 TF/VA228 Oval Flanged Ball Bearing Unit With Set Screw Locking, High Temperature, Cast Iron Housing, Iso

Part Number	FYTB 30 TF/VA228
Brand	SKF
Category	Flanged Bearings

Technical Specifications

Inner Diameter (d)	39.7 mm
Width (B)	141.5 mm
Dynamic Load Rating (C)	19.5 kN
Static Load Rating (C₀)	11.2 kN
Limiting Speed (Oil)	190 rpm
Weight	0.891 kg
Material	High temperature steel
Bore Type	Cylindrical
A1	13
B4	5
S1	22.2
Db1	77
Db2	83
Coating	Zinc-coated housing and manganese phosphate coated bearing
Lubricant	Solid lubricant
Set Screw	G2
Width Total	42.2
Housing Type	Flanged
Sealing Type	Non-contact
Sealing Unit	Without
Grease Fitting	Without
Shaft Diameter	30
Sealing Bearing	Shield and flinger on both sides
Material Bearing	High temperature steel
Material Housing	Cast iron
Shaft Diameter	30 mm
Relubrication Hole	Without
Bearing Width Total	38.1
Rubber Seating Ring	Without
Running In Required	No
Flanged Housing Type	Oval
Housing Overall Width	32.5
Operating Temperature	T
Attachment Bolt Diameter	12
Fastening Bolt Hole Type	Plain
Retaining Feature Inner Ring	Set screws
Maximum Operating Temperature	350
Centre Distance Between Bolt Holes	116.5
Number Of Bolt Holes For Fasteners	2
Attachment Bolts Recommended Inch Size	G
Attachment Bolts Recommended Metric Size	G
High Temperature Insert Bearing With Set Screws And Extended Inner Ring	YAR 206-2F/VA228

SKF FYTB 30 TF/VA228 Oval Flanged Ball Bearing Unit With Set Screw Locking, High Temperature, Cast Iron Housing, Iso

Name: SKF FYTB 30 TF/VA228 Oval Flanged Ball Bearing Unit With Set Screw Locking, High Temperature, Cast Iron Housing, Iso
Brand: SKF
SKU: FYTB 30 TF/VA228
